applicable material : Acrylic, Crytal, Glass, Leather
engraving area : 100mm*100mm
laser type : Fiber Laser
engraving speed : 0-700mm/s
graphic format supported : PLT
condition : New
cnc or not : NO
place of origin : China
laser source brand : Raycham
weight (kg) : 30 KG
key selling points : Easy to Operate
warranty : 1 Year
mode of operation : Pulsed
configuration : gantry type
feature : Air-cooled
Laser Type : SEMICONDUCTOR
After-sales Service Provided : Video technical support
After Warranty Service : Field maintenance and repair service
Application : Laser Engraving
Machinery Test Report : Provided
Video outgoing-inspection : Provided
Warranty of core components : 1 Year
Core Components : Pressure vessel, motor, Pump
Price : CN¥3,602.30/pieces
Laser power | 20Watt/30Watt |
Laser source | Fiber |
Light wave length | 1064nm |
Laser modulation mode | Coupling amplification |
Marking area | 70x70mm/110x110mm/175x175mm/200x200mm/300x300mm Optional |
Work table size | 150x210 mm |
Max marking speed | 7000mm/s |
Marking depth | 0.05~0.5mm(acc. to material) |
Min linewidth | 0.01mm |
Min marking character | 0.2mm |
Impulse frequency | 20~250kHz |
Cooling way | Air cooling |
Power supply | 220V/50Hz/1kVA |
Min focus facula diameter | 20um |
Re-position accuracy | 0.0025mm |
Laser indicator | Red dot pointer |
![]() |
20w 30w Mini Rotary Rotating Marker Laser Medals Dog Tages Engraved Machine Portable Fiber Laser Marking Machine for Leather Images |
